Ground Support & Logistics
Heavy-duty transport, specialized trailers, and operational support vehicles engineered to sustain force projection and fluid resupply across any terrain.
MAV (Multipurpose Articulated Vehicle)
The MAV is a compact yet powerful articulated wheel loader designed to deliver exceptional performance, maneuverability, and versatility. Equipped with a telescopic boom, it combines power and precision for efficient material handling.
Key Capabilities
- Equipped with a 57 HP diesel engine and a telescopic boom.
- Advanced transmission system ensures high torque and smooth operation.
- More than 100 attachments workable via easy hydraulic hookups.
- Ideal for agriculture, construction, landscaping, and municipal use.
Technical Specifications
| Engine Power | 57 hp Turbo |
|---|---|
| Max. Lifting Capacity | 1640 kg |
| Tipping Load Capacity | 2050 kg |
| Flow Rate | 83 L/min |
HPL (Hydraulic Platform Loader)
The Hydraulic Platform Loader is a self-propelled, air-transportable, aircraft loading and offloading vehicle. It automates the handling of heavy drop loads between loading ramps and military transport aircraft.
Key Capabilities
- Automates the transportation and handling of palletized cargo.
- Transports loads from the load preparation site to the aircraft tarmac.
- Constructed of high-grade materials and built to last in tough conditions.
- Fully compatible with C-130J and C-17 aircraft operations.
Technical Specifications
| Max Load Capacity | 20,000 kg |
|---|---|
| Max Platform Length | 32 feet |
| Compatibility | C-130J / C-17 |
| Application | Aircraft loading/offloading |
Advanced Tank Transporter Trailers
Heavy-duty trailer solutions engineered for extreme loads, rugged terrains, and mission-critical operations across defense, aviation, and strategic logistics environments.
Key Capabilities
- Designed to transport medium tanks, defence equipment, and heavy machinery.
- Operates seamlessly across metalled, un-metalled, and gravel tracks.
- 70-ton trailer variant built to meet IRC Class 70-R standards.
- Available in both mechanical and multi-axle hydraulic steering configurations.
Technical Specifications
| Payload Capacity | Up to 70 Tons |
|---|---|
| Standards | IRC Class 70-R |
| Suspension | Mechanical / Hydraulic |
| Terrains | Plains and Desert |
Flat Bed Transport Trucks
Engineered for safe and efficient transportation of dozers, excavators, and oversized military equipment, delivering superior load security and rugged performance across operations.
Key Capabilities
- Spring-assisted loading ramps require no maintenance and only one person to lift/lower.
- Equipped with 4 nos. of 10t/5t capacity chains for highly secure lashing.
- Front fixed choke and rear removable adjustable choke block.
- Open-deck loading enables rapid deployment and logistics supply chain management.
Technical Specifications
| Lashing Capacity | 10t/5t Chains |
|---|---|
| Safety Mechanism | Bottom pin locking |
| Ramp Design | Solid rod, spring-assisted |
| Auxiliary Features | Toolbox & Jerry Can Brackets |
Stallion MK-IV & LPTA 715 Lorries
Highly reliable 2.5T and 5/7.5T military transport lorries serving as the backbone of logistics and troop transportation for the Indian Armed Forces.
Key Capabilities
- Fully forward control type, tiltable cabin for ease of maintenance.
- Built-in cold starting devices enabling high altitude and extreme climate operations.
- Blackout lighting systems with variable modes for tactical night operations.
- Over 175,000 units successfully supplied and actively serving in the forces.
Technical Specifications
| Payload Capacity | 2500 - 7500 kg |
|---|---|
| Drivetrain | 4x4 / Auxiliary Gearbox |
| Maximum Speed | 85 - 100 km/h |
| Gradeability | 30° - 31.5° |
DAD Fuel & Water Bowsers
Mission-ready liquid logistics solutions engineered for defense operations, ensuring safe storage, precise dispensing, and uninterrupted sustainment support across extreme terrains.
Key Capabilities
- Stainless steel water tanks with PUF insulation for hygienic drinking water storage.
- Temperature variation not more than 5°C over 24 hrs in extreme climates (+50°C to -10°C).
- Fuel bowsers equipped with PTO driven pumps and precise liquid control flow meters.
- PTO operated pumps ensure rapid suction and high-speed fluid discharge.
Technical Specifications
| Fuel Bowser Capacity | 8KL (Aluminum Shell) |
|---|---|
| Water Bowser Capacity | 5KL (Stainless Steel 316L) |
| Pump Discharge Rate | Up to 1000 liters/min |
| Insulation | PU Foam Injected |
